JLM Series Vertical Iron Roller Rice Mill can meet the demands of scale rice mill, the advantages of whitening rice polisher at home and abroad are accepted by this machine. It has the following virtues: low energy consumption, large output, less broken rice and bright appearance of rice. After replacement of related parts, it can be used as millet, maize and other small grain polishing machine.
Features
1. Feeding from bottom to up,can work in series saving the elevator and space;
2. Compared with horizontal whitener, vertical whitener is evenness of rice milling and high productivity;
3. Screw propeller assists feeding; output flow is even without being affected by air volume;
4. Like other models of rice milling equipment, this machine combines an air-blowing fan (with an air volume 20% higher than that of similar products on the market) with an external fan, forming an air usage method that integrates blowing and suction. And the air intake volume is adjustable—this ensures the material whitening more even in the chamber, less chaff and low temperature.
Technical Specifications
| Model | JLM230 | JLM260 | JLM290 | |
| Output (t/h) | Rice | 4~6 | 6~10 | 10~15 |
| Millet | 2~4 | 4~6 | - | |
| Maize | 4~6 | 4~6 | 10~15 | |
| Power(kw) | Main body | 45-4P | 55-4P | 75-6P |
| Auger | 1.5-4P | 1.5-4P | 3-4P | |
| Jet blower | 1.5-2P | 1.5-2P | 4-2P | |
| OD of chaff inlet (mm) | Φ200 | Φ235 | Φ235 | |
| Weight(kg) | 1550 | 1750 | 2060 | |
| OD(mm) | 1250×1550×2060 | 1410×1590×2110 | 1780×1630×2408 | |
